VpCI® High Performance Coatings



Click on the links below to access product descriptions and other information regarding various VpCI® (Vapor Phase Corrosion Inhibitor)/MCI® (Migrating Corrosion Inhibitor) product lines.
NASA: Cortec Rust Inhibitor Coating is Used Extensively During Post Flight Operations; United Space Alliance, 3830-058
Wyland Foundation Letter of Thanks

Painter used VpCI® - 386 Clear Coat on his work.

Method Developed to Protect "Insurance Spares"
Description:
CorrBarrier is a waterbased coating which exhibits excellent properties over various substrates. Primarily designed for the automotive under-body/under-hood market, it also has application in industrial maintenance, railcar, truck/trailer, and heavy machinery.Designed as a clear primer, CorrBarrier has excellent chip resistance while maintaining a fast dry time.This coating is heavy metal free, has good early water resistance, excellent salt fog resistance and very low VOC content.
Application:
CorrBarrier may be applied by brush, spray, or dip. A film thickness of at least 4-5 wet mils (100-125 microns) is recommended for uncovered outdoor storage.
View Product Data Sheet

View Safety Data Sheet

Description:
CorrVerter is a water-based primer recommended for application to rusty or poorly prepared steel surfaces where further corrosion protection is required and good surface preparation is difficult to achieve. CorrVerter is formulated to penetrate rust, eliminate rust, penetrate to the bare metal, and stop further rusting.CorrVerter contains a novel chemical chelating agent that modifies the surface rust into a hydrophobic passive layer. CorrVerter combines the above mentioned chelating agent with a high solids waterborne latex with extremely low water vapor permeability. The combination of the active chelating agent with a film-forming latex, thickeners and dispersant offers a unique formulation for a primer with excellent protection against re-rusting.CorrVerter does not contain tannic or phosphoric acids, provides long-term corrosion protection for poorly prepared substrates, and can be topcoated with solvent-based and water-based paints with no bleeding. For outdoor applications VpCI-386 or VpCI-387 can be utilized. For indoor applications, VpCI-396 may also be used.The combination of CorrVerter and VpCI-396 provides the best immersion coating for submersion in water, salt water, hydro carbons and high salinity water.
Application: Outdoor storage, aircraft, elevators, storage tanks, vehicles, pumps, cargo holds, marine equipment.
Package:
CorrVerter is available in 5 gallon (19 liter) plastic containers. Keep product from freezing. The shelf life of the coating is one year.
View Product Data Sheet

View Safety Data Sheet

Description: CorShield® Gold is a brilliant true gold colored waterbased coating. It has excellent salt spray and humidity resistance similar to VpCI®-386 Aluminum and is available in one package system. CorShield® Gold provides protection in harsh, outdoor, unsheltered applications. The complex mixture of nontoxic organic inhibitors and a platelet type gold pigment offers protection that can compete with zinc rich coatings. This special combination of additives, a platelet pigment, and a polymer barrier, significantly retards the reaction of metal ionization and repels water. It protects against corrosive electrolytes and aggressive environments, thus preventing corrosion.
Package:CorShield® Gold is available in 5 gallon (19 liter) pails and 55 gallon (208 liter) drums, and liquid totes.
View Product Data Sheet

View Safety Data Sheet

Description: Water-reducible concentrate for transit protection of painted and unpainted surfaces.
Protection:Indoor or Outdoor Sheltered
Package:5 gal. (19 l), 55 gal. (208 l)
View Product Data Sheet

View Safety Data Sheet

Description: VpCI-386 HP is the next genration of high performance water-based acrylic coatings that provide superior corrosion protection in harsh outdoor, unsheltered applications. The unique formulation contains a mixture of non-toxic organic inhibitors and pigments that offer extended coating protection which strongly competes with heavy metal zinc-rich primers and paints.
Package:VpCI-386 HP is available in 5 gallon (19 liter) pails, 55 gallon (208 liter) metal drums, liquid totes, and bulk. Keep product from freezing.
View Product Data Sheet

View Safety Data Sheet

Description: EcoLine® 3690 is a biodegradable, biobased, ready-to-use temporary coating designed for severe marine and high humidity conditions. When applied on the surface, this product leaves an oily film, which provides excellent outdoor protection on any metal surface. The film is self-healing and moisture-displacing, providing superior protection against aggressive environments.
Application: • Biodegradable • Biobased: made with sustainable resources • Non-hazardous, non-toxic • Excellent indoor and outdoor protection • Provides multi-metal corrosion protection • Excellent lubricity • Temperature stable up to 180°F (82°C) • Low freezing point 0°F (-18°C) • Can be applied to painted surfaces • Meets MIL-PRF-16173E (Grade 2)
View Product Data Sheet

View Safety Data Sheet

Description:
EcoLine 3680 is a temporary coating formulated with USDA (United States Department of Agriculture) certified biobased, renewable and biodegradable raw materials; which allows use for corrosion protection of equipment where incidental contact with food is possible. EcoLine 3680 leaves a tenacious, dry-to-touch protective coating, wax-like film that can be removed with alkaline cleaners such as Cortec® VpCI-414.
View Product Data Sheet

View Safety Data Sheet

Description:
EcoPrimer™ is a core shell acrylic modified alkyd emulsion with bio-based primer. EcoPrimer™ provides good adhesion, salt spray resistance, and extremely low VOC. EcoPrimer™ has a fast drying time (20-30 minutes dry to touch). Its water-based formulation makes it easier to comply with environmental regulations governing solvents and VOC limits. Clean up is easy by using soap and water.Features:
• 30% bio based
• Water-reducible
• VOC compliant
• Fast drying
• Excellent adhesion
• Extremely low VOC
Application:
EcoPrimer may be applied by spray or brush. A film thickness of 1.5-4.0 dry mils (37.5-100 microns) is recommended. The coating dries to touch in 20-30 minutes; however it takes approximately one week before the coating is fully cured. Topcoats can be applied between 30 minutes and 8 hours after the primer is applied, depending upon the type of top coat and the drying conditions.Metals Protected:
• Carbon steel
• Stainless steel
• Galvanized steel**
• Aluminum**** A wash primer such as VpCI®-373 green applied at 0.5-1.0 mils (12.5-25 microns) is recommended before applying the EcoPrimer to these substrates.
Package:
EcoPrimer is available in 5 gallon pails (19 liters), 55 gallon (208 liter) drums, or 275 gallon (1040 liter) totes.Do not allow product to freeze.
View Product Data Sheet

View Safety Data Sheet

Description: Ecoshield® 386 Water Based Coating Powered by Nano VpCI™ is the first water based coating that can provide 1000 hours of salt spray performance at 1 mil (25 microns) DFT.The unique acrylic based formula uses a complex mixture of nano sized non-toxic organic inhibitors which provide protection which is superior to traditional corrosion inhibiting coatings.
Package:Ecoshield® 386 is available in 5 gallon (19 liter) pails, 55 gallon (208 liter) metal drums, liquid totes, and bulk.
View Product Data Sheet

View Safety Data Sheet

Description: EcoShield Barrier Coating is a water borne barrier coating that is recyclable and 100% repulpable, effectively eliminating the need to use traditional wax and polyethylene papers. In addition, the coating can be utilized on kraft and recycled paper to seal the surface from contaminants that could cause corrosion. The combination of a contaminant sealant and a repulpable coating for kraft paper makes EcoShield Barrier Coating a pioneer in the packaging industry. This material can also be used as a coating on liners for corrugated boxes providing a waterproof moisture barrier. EcoShield Barrier Coating also gives excellent oil and grease resistance.
Package:EcoShield Barrier Coating is available in 5 gallon (19 liter) plastic pails, 55 gallon (208 liter) metal drums, liquid totes, and bulk.
View Product Data Sheet

View Safety Data Sheet

Description: Cortec® EcoSonic® ESD Paper combines corrosion inhibiting and static-dissipative properties to provide a complete packaging paper for your valuable items. This product eliminates static electricity buildup through the use of an environmentally friendly coating made from soybean oil that is coated onto the surface of the paper. EcoSonic® ESD Paper performs better on the static half life test (a test with an environment consisting of little or no humidity) than papers with conventional anti-stat coatings consisting of Alkyl Ammonium Chlorides, typical ethoxylated amines, typical imidazolines, phosphated esters, and nonionic based antistat coatings.
Package:Custom sizes and constructions available upon request.
View Product Data Sheet

View Safety Data Sheet

Description:
VpCI-2026 Top Coat is a 100% solids, 2-component, novolac epoxy coating designed for environments that require a high degree of chemical or temperature resistance. VpCI-2026 Top Coat is available in clear, and can be colored with any of the VpCI-2026 HPCS colorants.
Application:
The recommended application of this product involves pouring it in a narrow line directly onto the surface and then spreading it with a squeege. Spread the coating in a continuous manner from one side of the area being coated to the other. Immediately follow with a 3/8” (0.95cm) nap shed resistance roller. The VpCI- 2026 must be rolled as evenly as possible. To do this, roll forward in a straight line and then roll the same column backwards. Overlap the next column to be rolled by 1/2” (1.27cm) with the previously rolled column. Avoid excess agitation of the liquids with the roller. This will lessen chances of bubbling of the final film. The individual(s) applying the VpCI-2026 Top Coat should be wearing “spiked sandals”.
View Product Data Sheet

View Safety Data Sheet

Description: VpCI®-280 is a fast drying, versatile, industrial finishing enamel for manufacturers of metal products. This enamel offers a quick dry time, high gloss, and good color and gloss retention. It is ideal for industrial OEM users, including agricultural and construction equipment. Regulatory benefits include very low levels of VOC and Hazardous Air Pollutant Solvents.
